BittWare 385A FPGA Accelerator Card
BittWare 385A FPGA Accelerator Card offers a powerful PCIe computing and I/O platform for FPGA development and deployment. The BittWare 385A FPGA Accelerator Card is designed to support a range of application areas. These include high-performance computing, image processing, and network analytics.
Features
- Intel Arria 10 GX 1150
- 2x QSFP+ for 10/40Gbps
- OpenCL BSP
Specifications
- FPGA
- Intel Arria 10 GX
- 1150 GX F1517 NF40 package
- I/O speed grade -3 core speed grade -2
- Intel Arria 10 GX
- On-board Flash
- Flash memory for booting FPGA
- On-board memory
- Two banks of DDR3 SDRAM x 72 bits
- 4GB per bank (8GB total /16GB and 32GB version also available)
- 2133MT/s per bank
- Host interface
- x8 Gen3 interface direct to FPGA
- QSFP cages
- 2 QSFP+ cages on front panel connected directly to FPGA via 8 transceivers
- User programmable low jitter clocking supporting 10/40 GbE
- Each QSFP can be independently clocked
- Clocking options:
- Network recovered with jitter attenuation
- QSFP clocking: user programmable, or CPRI, 1GbE
- External clock input, 1PPS input
- Cooling
- Single-width active heatsink (embedded fan) - standard
- Single-width passive heatsink - optional
- Electrical
- On-board power derived from 12V PCIe slot
- Power dissipation is application dependent
- Typical max power consumption 75W
- Environmental
- 5°C to 35°C Operating temperature
- Quality
- Manufactured to ISO9001:2008 IPC-A-610-Class
- RoHS compliant
- Form factor
- Half-height, half-length PCIe single-slot board
- 167.6mm x 68.9 mm x 17mm
- FPGA development
- BIST – Built-In Self-Test for CentOS 7 provided with source code (pinout, gateware, PCIe driver & host test application)
- Application development
- Supported design flows – Intel FPGA OpenCL SDK, Quartus Prime Pro (HDL, Verilog, VHDL, etc.)
Kit Contents
- 385A FPGA board
- USB cable (front panel access)
- Built-In Self-Test (BIST)
- OpenCL HPC Board Support Package (BSP)
- 1-year access to online Developer Site
- 1-year hardware warranty
Applications
- Compute, Network and Storage
- Finance and Risk Analysis
- Datacenter
- HPC
- Communications (wireless and wireline)
- Industrial, Broadcast, Embedded
- Medical
- Automotive
Block Diagram
Associated Software
- SWPEQRTSFLT Quartus Prime Pro Edition software floating-node subscription
- SWPEFIXUP Quartus Prime Pro Edition software and Standard Edition software fixed-node subscription
- SWPEFLTADD Development Software Pro Edition float additional seats to Pro Edition float, includes subscription updates for both Standard and Pro Editions
- SWRPEQRTSFLT Quartus Prime Pro Edition software per-seat renewal for a floating-subscription license
- SWRPEQRTSFIX Quartus Prime Pro Edition software per-seat renewal for a fixed-subscription license
- SWPEFLTUPADD Quartus Prime Pro Edition software additional floating-node seat for floating-subscription products and subscription software updates for the remaining Standard Edition software license duration
- SWPEFLTUP Quartus Prime Pro Edition software floating-node subscription
- BittWare/Molex 15 hours of email and telephone support
